MINI DOME 15M IR AHD CAMERA ANALOG HD CAMERA 1080P 3.6MM

Be The First To Review This Product!

Help other KG Electronic Pty Ltd users shop smarter by writing reviews for products you have purchased.

Write a product review

MINI DOME 15M IR AHD CAMERA ANALOG HD CAMERA 1080P 3.6MM

  • AHD high definition camera at 1080P resolution

  • Low illumination 1/2.8" SONY 2.43M CMOS sensor

  • 3.6mm lens

  • 10-15m IR distance

  • HD AHD 1080P, 800TVL analogue dual-output

  • AHD coaxial transmission distance up to 500m

  • AHD/analogue signal

  • D-WDR, 2D/ 3D NR, defog, CRR

  • Motion detection, Privacy zones, BLC and HLC

  • OSD Menu

  • Sensor: 1/2.8" SONY 2M pixels CMOS

  • Effective pixels: 1920*1080

  • HD AHD output: 1080P

  • Resolution:  800TVL (CVBS input)

  • Min. Illumination: 0 Lux (IR ON) colour: 0.1Lux/F1.2; B/W: 0.01Lux/F1.2

  • Scan System: Progressive scan

  • Electronic Shutter: Auto/ Manual (X30~1/50000) / FLK

  • S/N Rate: ≥50db(AGC OFF)

  • Video output:  1.0Vp-p composite video output, 75O

  • Output  model: PAL/ NTSC adjustable

(DMM15AHDW)

Standard Consumer Warranty
MINI DOME 15M IR AHD CAMERA ANALOG HD CAMERA 1080P 3.6MM AHD high definition camera at 1080P resolution Low illumination 1/2.8" SONY 2.43M CMOS sensor 3.6mm lens 10-15m IR distance HD AHD 1080P, 800TVL analogue dual-output AHD coaxial transmission distance up to 500m AHD/analogue signal D-WDR, 2D/ 3D NR, defog, CRR Motion detection, Privacy zones, BLC and HLC OSD Menu Sensor: 1/2.8" SONY 2M pixels CMOS Effective pixels: 1920*1080 HD AHD output: 1080P Resolution:  800TVL (CVBS input)  Min. Illumination: 0 Lux (IR ON) colour: 0.1Lux/F1.2; B/W: 0.01Lux/F1.2  Scan System: Progressive scan Electronic Shutter: Auto/ Manual (X30~1/50000) / FLK S/N Rate: ≥50db(AGC OFF) Video output:  1.0Vp-p composite video output, 75O Output  model: PAL/ NTSC adjustable
Model # DMM15AHDW
Barcode # 9328202024305
Brand DOSS
Shipping Weight 0.3800kg
Shipping Width 0.250m
Shipping Height 0.100m
Shipping Length 0.250m
Shipping Cubic 0.006250000m3
Type Dome
