Manson 5AMP 0-30V DC Power Supply Digital Bench Top Dark Grey

This item comes with a 12-month warranty.

Manson 5AMP 0-30V DC Power Supply Digital Bench Top Dark Grey is a completely solid-state, compact, well regulated, constant voltage power supplies suitable for service field, hobby & telecommunication equipment use. It provides three different voltages of output for different usage. The NP-9615 is designed for general electronic servicing, school electronics, laboratory use and for the hobbyist. Can be used as either a constant voltage supply with current limiting or as constant current source with voltage limiting. The NP-9615 has three independent outputs, two are of fixed voltage and one adjustable voltage. Features: Overload and Short Circuit Protection: Prevent the unit from overload and short circuit. When the unit is under the condition of overload or short circuit, the output current will be limited. Independent 5V, 12V Easy Snap-On output terminals to make it easy to use for TTL and CMOS circuit testing. The grounding of the output terminals is independent that the output can be connected in series to make a higher output voltage. Outputs: 0-30 V adjustable 5 V 500 mA Snap-On 12 V 500 mA Snap-On Colour: Dark Grey Output Voltage: 0-30VDC Rated Output Current: 5A Fixed Output Voltage 1: 5V DC 0.5A Continuous 1A Maximum Fixed Output Voltage 2: 12V DC 0.5A Continuous 1A Maximum Ripple & Noise (r.m.s.): 5mV Load Regulation: 30mV Line Regulation: 10mV Input Voltage: 230Vac/50Hz (120Vac/60Hz or on request) V meter Range: 3 Digit Display A meter Range: 3 Digit Display Meters' Accuracy: 1%+2 Digits Output Terminals: One Variable Main Output Screw On Type/Two Snap-On Fixed Voltage 1 and 2 Cooling System: Thermostatic Control Fan Protection: Overload, Short Circuit Approvals:CE EN61558,EN55014 Dimensions Approx.:  20.5 x 28 x 11.5 cm Weight Approx.: 6.5 kg

• Colour: Dark Grey

• AU/NZ Plug

• Output Voltage: 0-30VDC

• Rated Output Current: 5A

• Fixed Output Voltage 1: 5V DC 0.5A Continuous 1A Maximum

• Fixed Output Voltage 2: 12V DC 0.5A Continuous 1A Maximum

• Ripple & Noise (r.m.s.): 5mV

• Load Regulation: 30mV

• Line Regulation: 10mV

• Input Voltage: 230Vac/50Hz (120Vac/60Hz or on request)

• Meter Type: LCD

• V meter Range: 3 Digit Display

• A meter Range: 3 Digit Display

• Meters' Accuracy: 1%+2 Digits

• Output Terminals: One Variable Main Output Screw On Type/Two Snap-On Fixed Voltage 1 and 2

• Cooling System: Thermostatic Control Fan

• Protection: Overload, Short Circuit

• Approvals:CE EN61558,EN55014

• Dimensions Approx.:  20.5 x 28 x 11.5 cm

• Weight Approx.: 6.5 kg
