Manson 1-20VDC 5A Slim Multi-Voltage Switchmode Power Supply LCD

Be The First To Review This Product!

Help other KG Electronic Pty Ltd users shop smarter by writing reviews for products you have purchased.

Write a product review

This series of 100W Switching Mode Power Supplies with Current Limiting Control is designed with the objectives of high accuracy, compactness and easy portability.

4 digit display LCD of voltage and current for high precision. The slim tower housing makes it ideal for a tight workbench. It is light and conveniently portable and a collapsible handle. The large and illuminated LCD display provides clear and sharp readings even under dim light. The output power on-off switch allows safe and handy operations. The Tracking OVP (output over-voltage protection) ensures better and tighter protection to voltage sensitive loads. It has good line and load regulations, high efficiency and low ripple and noise that are typical of advanced switching mode power supply.

Manson 1-20VDC 5A Slim Multi-Voltage Switchmode Power Supply LCD meets the CE safety standards EN-61010 for laboratory grade power supply and respective EMC standards.

Features:

  • Automatic Cross over CV and CC mode

  • Illuminated LCD indications of A, V, Output On-Off, CC and CV

  • 4 digit displays of Volt and Amp meters

  • Voltage and Current Controls

  • Compact slim tower housingCollapsible handle

  • Output power on-off switch at the front panel

  • Natural Convection

  • Tracking OVP(output over-voltage protection), ShortCircuit, overload and over temperature protections

  • Good line, load regulations and low ripple and noise

  • Rotary encoder control

  • CE approvals

(NSP2050)

This item comes with a 12-month warranty.

Manson 1-20VDC 5A Slim Multi-Voltage Switchmode Power Supply LCD meets the CE safety standards EN-61010 for laboratory grade power supply and respective EMC standards. Features: Automatic Cross over CV and CC mode Illuminated LCD indications of A, V, Output On-Off, CC and CV 4 digit displays of Volt and Amp meters Voltage and Current Controls Compact slim tower housingCollapsible handle Output power on-off switch at the front panel Natural Convection Tracking OVP(output over-voltage protection), ShortCircuit, overload and over temperature protections Good line, load regulations and low ripple and noise Rotary encoder control CE approvals Specifications Colour: White Input Voltage...200-240VAC, 50/60Hz~(or on request) Full Load Input Current at 230VAC...0.83A Output Voltage Adjustable Range...1-20VDC Output Current Adjustable Range...0-5A Voltage Regulation Load from 10% to 100% Variation...50mV Line from 180 to 264VAC Variation...20mV Ripple and Noise in r.m.s....5mV Ripple and Noise (peak to peak)...30mV Current Regulation Load from 10% to 100% Variation...20mA Line from 180 to 264VAC Variation...20mA Ripple and Noise (peak to peak)...20mA Switching Operation Frequency...80KHz to 120KHz Power Factor...0.68 Efficiency at Maximum Power...84% Display 4 Digit Volt. Meter Accuracy...±1% +5 counts for range V =5V ±1% +3 counts for range V >5V Curr. Meter Accuracy...±1% +5 counts for range V =2A ±1% +3 counts for range V >2A LCD Indication...C.C., C.V. , Amp, Volt, output on/off Protection...Short Circuit, Overload, Over Tempertature, Tracking OVP Approvals...CE EMC:EN55011 LVD:EN61010 Cooling System...Natural Convection Dimensions (WxHxD) 70x150x250mm 2.8x6x9 inch Weight...Approx 2kgs 4.4lbs

Specifications

  • Colour: White

  • Input Voltage...200-240VAC, 50/60Hz~(or on request)

  • Full Load Input Current at 230VAC...0.83A

  • Output Voltage Adjustable Range...1-20VDC

  • Output Current Adjustable Range...0-5A

Voltage Regulation

  • Load from 10% to 100% Variation...50mV

  • Line from 180 to 264VAC Variation...20mV

  • Ripple and Noise in r.m.s....5mV

  • Ripple and Noise (peak to peak)...30mV

Current Regulation

  • Load from 10% to 100% Variation...20mA

  • Line from 180 to 264VAC Variation...20mA

  • Ripple and Noise (peak to peak)...20mA

  • Switching Operation Frequency...80KHz to 120KHz

  • Power Factor...0.68

  • Efficiency at Maximum Power...84%

  • Display...4 Digit

  • Volt. Meter Accuracy...±1% +5 counts for range V =5V

  • .....................................±1% +3 counts for range V >5V

  • Curr. Meter Accuracy...±1% +5 counts for range V =2A

  • .....................................±1% +3 counts for range V >2A

  • LCD Indication...C.C., C.V. , Amp, Volt, output on/off

  • Protection...Short Circuit, Overload, Over Tempertature, Tracking OVP

  • Approvals...CE EMC:EN55011 LVD:EN61010

  • Cooling System...Natural Convection

  • Dimensions (WxHxD) 70x150x250mm 2.8x6x9 inch

  • Weight...Approx 2kgs 4.4lbs

Model # NSP2050
Brand MANSON
Shipping Weight 2.5000kg
Shipping Width 0.270m
Shipping Height 0.100m
Shipping Length 0.180m
Shipping Cubic 0.004860000m3
Type Power Supply
