Simplecom CM323 3-Way HDMI 2.0 Switch to Ultra HD 4K HDR Splitter

Be The First To Review This Product!

Help other KG Electronic Pty Ltd users shop smarter by writing reviews for products you have purchased.

Write a product review

Simplecom CM323 3 Way HDMI 2.0 Switch 3 In 1 Out Splitter HDCP 2.2 4K @60Hz UHD HDR

CM323 is a 3 Way HDMI 2.0 4K switch for your latest gaming or home theatre setup. It widely compatible with most HDMI devices and supports HDMI 2.0 and HDCP 2.2, ideal for latest online streaming box and game console with 4K UHD HDMI output.

This HDMI 2.0 4K switch is also backward compatible with previous HDMI revisions with 1080p / 720p video resolution devices.

Easy plug & play operation simply plug in the HDMI input sources into the input connections and the output connection to your TV or projector. It will automatically switch to the currently active input source if there is only one active input. If there are multiple active inputs, you can select the input by press the select button on the switch.

Features:

  • Widely compatible HDMI devices with HDMI 2.0 and HDCP 2.2 support

  • Supported Video Resolutions up to 4Kx2K @ 60Hz

  • Support HDR and 4:4:4 RGB output

  • Backward compatible with previous HDMI revisions

  • Supports highest bandwidth up to 18Gpbs. Perfect for PS4 Pro, Xbox One S, Chromecast Ultra, Direct TV, Roku Premiere+, Fire TV, PCs etc.

  • Supports Auto Switching to active input source port*

  • Plug-and-Play, Self Powered

HDMI version: HDMI 2.0 (backward compatible with previous HDMI revisions)
HDCP version: HDCP 2.2 (backward compatible with previous HDCP revisions)
Video Amplifier Bandwidth: 18Gpbs/250MHZ
Frequency: 25MHZ-165MHZ
Support Video Format: Ultra HD 4K/2K (3840X2160) @ 60Hz / 1080p / 1080i / 720p / 576p / 480p / 576i / 480i / 3D Video
Support Video Color: 12 bit Deep Color Per Channel
Support Audio Format: Dolby Digital, DTS-HD, Dolby-TrueHD, DTS, LPCM
Operating Temperature: 0°C to 70°C
Operating Humidity: 10% to 85% RH(no condensation)

Includes:

  • 1x Simplecom CM323 3 Way HDMI 2.0 Switch 3 IN 1 OUT Ultra HD 4K 60Hz HDR HDCP 2.2

NOTE:
Apple TV and some online streaming box keeps its HDMI port active even in the sleep state. Hence, auto-switching may not work with them. Manual switching can still be used in this scen

(CBSI-CM323)

This item comes with a 12-month warranty.

Model # CBSI-CM323
Barcode # 9350414001300
Brand SIMPLECOM
Shipping Weight 0.0600kg
Shipping Width 0.210m
Shipping Height 0.020m
Shipping Length 0.140m
Shipping Cubic 0.000588000m3
Type Switch Box
