HDMI Wall Plate Extender/Transmitter

This item comes with a 12-month warranty.

A neat and simple wall plate high definition HDMI extender kit. This kit extends your high definition AV source from your Blu-ray DVD Players, PS3 and XBOX etc. up to a maximum 60m via CAT5E/6 cables through the wall cavities. Supports full 1080P high definition of up to 60m. Integrates an infra-red control extender for full controllability from the receiving end. RJ45 connections on the rear of both units make it for easy connection. Each set includes one transmitter and one receiver Modular design Connect with single Cat5E/6 cable to reach a longer distance than HDMI cable Transmission distance could be up to 60m with 1080P video format Auto adjustment of feedback, equalisation and amplify Up to 2.25Gbits signal rates in support of 1080P display With Infrared control signal passing through Compatible with the 3D format Note Foxtel iQ2/iQ3 Incompatible Operating Temprature Range: −5 to +35°C Operating Humidity Range: 5 to 90% RH (No Condensation) Input Video Singal: 0.5-1.0 Volts P-P Input DDC Signal: 5 Volts p-p(TTL) Support Video Format: DTV/HDTV: 480i/576i/480P/576P/720P/1080i/1080p/3D video format Video Output: HDMI Support Audio Format: DTS-HD Master Audio, Dolby true-HD etc. Power consumption: 3watts (Maximum) Dimension (LxWxH): 115x70x35mm IR wavelength & Frequency: Wavelength 940nm, frequency 38kHz Net Weight: 260g (Pair) Power supply: 2 x DC/5V 1A (included) Transmission Distance: 1080P 8-bit 60m (Maximum) over CAT5E/CAT6/24AWG/Solid (recommend to use 23AWG Cat6cable)

• Operating Temprature Range: −5 to +35°C

• Operating Humidity Range: 5 to 90% RH (No Condensation)

• Input Video Singal: 0.5-1.0 Volts P-P

• Input DDC Signal: 5 Volts p-p(TTL)

• Support Video Format: DTV/HDTV: 480i/576i/480P/576P/720P/1080i/1080p/3D video format

• Video Output: HDMI

• Support Audio Format: DTS-HD Master Audio, Dolby true-HD etc.

• Power consumption: 3watts (Maximum)

• Dimension (LxWxH): 115x70x35mm

• IR wavelength & Frequency: Wavelength 940nm, frequency 38kHz

• Net Weight: 260g (Pair)

• Power supply: 2 x DC/5V 1A (included)

Transmission Distance:

• 1080P 8-bit 60m (Maximum)

• over CAT5E/CAT6/24AWG/Solid (recommend to use 23AWG Cat6cable)
