Ideal for home, SOHO office, office, and back-office applications, the Value Pro Series adopts line-interactive topology with Automatic Voltage Regulation (AVR) function to offer stabilized AC power output.
The products provide a multifunctional LCD readout to display clear power and battery conditions.
The data line protection with high-speed transmission safeguards phones, network, and communication equipment against surge/spike as well as supplies 1Gbps speed to transmit data.
The products' power management software achieves real-time monitoring and configuration.
Features:
-
Line-interactive UPS Topology
-
Energy Saving Technology
-
Automatic Voltage Regulation (AVR)
-
Overload Protection
-
Surge and Spike Protection
-
High-Speed Ethernet Data Transmission*
-
LCD Status Display
-
PowerPanel® Management Software
-
Tower Form Factor
Application:
-
Home
-
SOHO Office
-
Office
-
Back Office
Includes:
-
1x CP Value Pro 1600VA UPS
(CPVP1600ELCD)
This item comes with a 2-year warranty.
General
-
UPS Topology: Line-interactive
-
Energy Saving Technology: GreenPower UPS™ Bypass Technology
Input
-
Nominal Input Voltage (Vac): 230 ± 10%
-
Input Voltage Range (Vac): 167 ~ 295
-
Input Frequency (Hz): 50 ± 5, 60 ± 5
-
Rated Input Current (A): 6.96
-
Input Connector Type: IEC C14
Output
-
Capacity (VA): 1600
-
Capacity (Watts): 960
-
On Battery Waveform: Simulated Sine Wave
-
On Battery Voltage(s) (Vac): 230 ± 10%
-
On Battery Frequency (Hz): 50 ± 1%, 60 ± 1%
-
Automatic Voltage Regulation (AVR): Single Boost, Single Buck
-
Overload Protection: Circuit Breaker
-
Outlet(s) - Total: 4
-
Outlet Type: AU x 4
-
Outlet(s) - Battery & Surge Protected: 3
-
Outlet(s) - Surge-Only Protected: 1
-
Typical Transfer Time (ms): 4
Battery
-
Runtime at Half Load (min): 11
-
Runtime at Full Load (min): 2
-
Typical Recharge Time (Hours): 8
-
User-replaceable: No
-
Battery Type: Sealed Lead-acid
-
Surge Protection & Filtering
-
Surge Suppression (Joules): 450
-
EMI/RFI Filtration: Yes
-
Phone/Network Protection RJ11/RJ45 (Combo): 1-in, 1-out
Management & Communications
-
LCD Panel: Yes
-
LED Indicators: Power On
-
HID Compliant USB Port(s): 1
-
Serial Port: RS232
-
Audible Alarms: Battery Mode, Low Battery, Overload, UPS Fault
-
Power Management Software: PowerPanel® Personal
Physical
-
Form Factor: Tower
Physical Size - UPS Module
-
Dimensions (WxHxD) (mm.): 100 x 281 x 355
-
Weight (kg.): 10.42
Environmental
-
Operating Temperature (°C): 0 ~ 40
-
Operating Relative Humidity (Non-condensing) (%): 0 ~ 90
-
Online Thermal Dissipation (BTU/hr): 68
Certifications
-
Certifications: CE, RCM
-
RoHS: Yes
Model # | CPVP1600ELCD |
Barcode # | 4712856274646 |
Brand | CYBERPOWER |
Shipping Weight | 10.4200kg |
Shipping Width | 0.420m |
Shipping Height | 0.160m |
Shipping Length | 0.370m |
Shipping Cubic | 0.023479000m3 |
Type | Desktop/Freestanding UPS |
