Simplecom DA315 USB 2.0 Male to HDMI 1080p FHD Female Adapter/Converter

Be The First To Review This Product!

Help other KG Electronic Pty Ltd users shop smarter by writing reviews for products you have purchased.

Write a product review

Simplecom DA315 HDMI to USB 2.0 Video Capture Card Full HD 1080p for Live Streaming Recording - Elgato, Atomos Connect

DA315 is a compact HDMI to USB 2.0 video capture card, which allow you to capture HDMI video in Full HD 1080p. You can simply hook up your camera, camcorder, game console or other HDMI source to your PC or Mac for recording or streaming.

Compliant with UVC (USB Video Class) and UAC (USB Audio Class), it’s Plug in and Play and easy to use, no driver installation is required. Ideal for video recording, live streaming, video conference, and compatible with most mainstream capture software and live platforms.

Features:

  • Easy Operation, Plug in and Play, No driver required

  • Support HDMI input resolution up to 4K

  • Support USB output resolution up to 1080p

  • Compliant with UVC (USB Video Class) and UAC (USB Audio Class)

  • No external power supply required, compact and portable

  • Compatible with most mainstream capture software, such as VLC, OBS, Amcap, etc.

  • Ideal for video recording, live streaming and video conference

  • Support Windows, Mac OS

HDMI Input Resolution Support: up to 3840x2160@30Hz
USB Output Resolution Support: up to 1920x1080@30Hz
Video Input Format: 8 / 10 / 12-bit Deep Color
Video Output Mode: YUV / JPEG
Audio Format Support: L-PCM
Input HDMI Cable Support: < 15m (AWG26 Standard HDMI Cable)
Maximum Working Current: 0.4A / 5VDC
Operating temperature range: (-10 to + 55 Celsius)
Dimensions Approx: (L x W x H): 64 x 28 x 13mm
Weight: 21.4g
Material: Alloy Aluminium

System Requirement

  • CPU: Quad Core Intel Core i5 or higher, Core i7 CPU is recommended

  • RAM: 4GB or higher

  • Graphic Card: NVIDIA GT630 or higher

  • Operating System: Windows 10 (64-bit), Mac OS X10.9 or higher

Includes:

  • 1x Simplecom DA315 HDMI to USB 2.0 Video Capture Card Full HD 1080p

Important Note:

  • Avoid USB hub or extension cable, connect to computer USB port directly

  • Low performance PC will cause lag when recording or steaming

  • Make sure select right audio input device if more than one audio source connected

  • YUY2 Video format is not supported

  • Certain Canon and Fujifilm camera models are not supported, e.g. EOS 6D, 6D Mark II, M10, Rebel

(HXSI-DA315)

This item comes with a 12-month warranty.

Model # HXSI-DA315
Barcode # 9350414001911
Brand SIMPLECOM
Shipping Weight 0.0200kg
Shipping Width 0.190m
Shipping Height 0.010m
Shipping Length 0.110m
Shipping Cubic 0.000209000m3
Type HDMI Video Capture
