ACCESS KEYPAD ONLY REQUIRES HOUSING

This item comes with a 12 months warranty

ACCESS KEYPAD ONLY REQUIRES HOUSINGAIPHONE DOOR ACCESS CONTROL Aiphone AC10U is a keypad mechanism only designed for integrating with a custom user-supplied panel Up to 100 user codes (#1 relay: 60, #2 relay: 40) 4, 5 or 6 digits user code length 2 relays (both of relays have N/O and N/C) Keypad lockout function Anti-tailgate function One push door release with external timer connection Key pad illumination SPECIFICATIONS: Power Source 12 – 24V AC/DC Consumption AC: Max. 100mA DC: Max. 70mA Relay Outputs: 2 Contact rating: 24V AC/DC 3A (resistive load) 1A (inductive load) Dry contact: N/O or N/C Operating time: 1- 99 secs Access Code Number: Up to 100 (#1: 60, #2: 40) Code length: 4 – 6 digit Wiring Two conductors Wiring Distance Unit~Power supply Door strike 0.65 – 1.0mm 100m Unit power 0.65 – 1.0mm 300m Exit/entry button & timer 0.65 – 1.0mm 300m IP Rating IP54
