9 WAY 13.8VDC 10A POWER SUPPLY WITH UPS PFC SURGE PROTECTION

  • Full AC input range: 100~240V

  • Withstand 300VAC surge input for 5 seconds

  • Protection: short circuit / overload / over voltage / over temperature

  • DC Voltage: 13.8V

  • Current: 10A

  • Power: 138W

  • Ripple and Noise: ≤200mVp-p

  • Voltage ADJ. Range: 13.8V ±10%

  • Voltage Accuracy: ±10%

  • Set-up Time: 1500ms, 50ms/230VAC 1500ms, 50ms/115VAC(at full load)

  • Hold up Time: 15ms/230VAC 12ms/115VAC(at full load)

  • Voltage Range: 100V~240VAC

  • Frequency Range: 47~63Hz

  • Efficiency (Type): 80%~95%

  • Over Load: 105%~150% (rated load)

  • Over Voltage: 115%~150% (rated output voltage)

  • Shorted Circuit: Fuse Tube

  • Operating Temp. & Hum.: -10°C~45°C; 20%~90%RH (non-condensing)

  • Storage Temp. & Hum.: -25°C~+70°C 20%~95%

  • Dimensions Approx.: 324 x 250 x 850 mm

(PWU0912W10)

Standard Consumer Warranty
9 WAY 13.8VDC 10A POWER SUPPLY WITH UPS PFC SURGE PROTECTION Full AC input range: 100~240V Withstand 300VAC surge input for 5 seconds Protection: short circuit / overload / over voltage / over temperature DC Voltage: 13.8V Current: 10A Power: 138W Ripple and Noise: ≤200mVp-p Voltage ADJ. Range: 13.8V ±10% Voltage Accuracy: ±10% Set-up Time: 1500ms, 50ms/230VAC 1500ms, 50ms/115VAC(at full load) Hold up Time: 15ms/230VAC 12ms/115VAC(at full load) Voltage Range: 100V~240VAC Frequency Range: 47~63Hz Efficiency (Type): 80%~95% Over Load: 105%~150% (rated load) Over Voltage: 115%~150% (rated output voltage) Shorted Circuit: Fuse Tube Operating Temp. & Hum.: -10°C~45°C; 20%~90%RH (non-condensing) Storage Temp. & Hum.: -25°C~+70°C 20%~95% Dimensions Approx.: 324 x 250 x 850 mm
Model # PWU0912W10
Barcode # 9328202031808
Brand DOSS
Shipping Weight 2.8500kg
Shipping Width 0.370m
Shipping Height 0.090m
Shipping Length 0.250m
Shipping Cubic 0.008325000m3
Type Power Supply
