Doss 2.5AMP 0-30V DC Power Supply Digital Bench Top Black

Be The First To Review This Product!

Help other KG Electronic Pty Ltd users shop smarter by writing reviews for products you have purchased.

Write a product review

Featuring TWIN LCD Voltage & Current Meters.DC Regulated power supply, 0 to 30 volts, 0 to 2.5 Amps, with Fixed 5 Volt and 12 Volt Outputs.

Completely solidstate, compact, well regulated, constant voltage power supply suitable for service field, hobby & telecommunication equipment use.

  • Variable output: Voltage.. 0-30VDC Current.. 0-2.5Amps
  • Low current push terminals or high current post terminals
  • Current & voltage LCD meters
  • Ripple & noise (RMS): 5mV
  • Line regulation: 0.05% +/- 10mV
  • Lo ad regulation: 0.05% +/- 10mV
  • Fixed voltage: 5V / 500m A max, 12V / 500mA max
  • Power source: 220/240VAC 50Hz
  • Dimensions.: 150 x 145 x 200mm
  • Weight: 2.8Kg

(EP613)

This item comes with a 12 month warranty

Featuring TWIN LCD Voltage & Current Meters.DC Regulated power supply, 0 to 30 volts, 0 to 2.5 Amps, with Fixed 5 Volt and 12 Volt Outputs. Completely solidstate, compact, well regulated, constant voltage power supply suitable for service field, hobby & telecommunication equipment use. Variable output: Voltage.. 0-30VDC Current.. 0-2.5Amps Low current push terminals or high current post terminals Current & voltage LCD meters Ripple & noise (RMS): 5mV Line regulation: 0.05% +/- 10mV Lo ad regulation: 0.05% +/- 10mV Fixed voltage: 5V / 500m A max, 12V / 500mA max Power source: 220/240VAC 50Hz Dimensions.: 150 x 145 x 200mm Weight: 2.8Kg
Model # EP613
Barcode # 9328202023803
Brand DOSS
Shipping Weight 4.8000kg
Shipping Width 0.220m
Shipping Height 0.170m
Shipping Length 0.170m
Shipping Cubic 0.006358000m3
Type Regulated Bench Top DC
